Wordsworth

WordsworthBased on an original design the Wordsworth Lantern has been modernised to incorporate a whole array of control gears, light sources and communication systems thus giving you an original design which meets the demands of today’s modern society.

Key Features

Manufactured from UV stabilised polycarbonate
Various optical options and lamp types
High resistance to vandalism, low maintenance
Available in full range of RAL and BS polyester powder coated paint finishes

Wordsworth-Globe1107







DXF drawing file

Lantern Sizes

Max Height (A) Max Width (B) Mounting Height Weight Windage
3) 615mm Ø500mm 4m-5m 7kg 0.24m²
4) 560mm Ø450mm 3m-4m 6.5kg 0.21m²
5) 495mm Ø400mm 2m-3m 6kg 0.15m²

Wordsworth Range - Cropped

Fixing Options

  • The Keats globe comes with a cast aluminium base suitable for mounting on a Ø60mm pole
  • A universal spigot adaptor is available which sleeves inside a Ø76mm column shaft and gives a Ø60mm spigot for the globe to attach to

Light Sources & Reflectors

Size CPO MH HPS PL LED
3 45w - 140w 50w - 70w 50w - 70w 11w - 57w 470 - 1055lm
4 45w - 140w 50w - 70w 50w - 70w 11w - 57w 470 - 1055lm
5 45w - 140w 50w - 70w 50w - 70w 11w - 42w 470 - 1055lm

Key

CPO Cosmopolis
MH Metal Halide
HPS High Pressure Sodium (SON)
PL Compact Fluorescent
LED Light Emitting Diode

Lighting Reflectors
> Refractor
> Louvre
> Heat shield

Control Gears & Systems

Gear
> Magnetic gear
> Electronic ballasts

Switching
> Photocells
> Part night cells

Columns & Brackets

Click here for more examples of columns
Click here for more examples of brackets

Wordsworth Brackets & Columns
